AC Line Filter
Common Mode:UU9VF/UU9HF.
In addition to the standard versions of parameters shown here, custom designs are available to meet your exact require ments.
Ideally used in Multi-function telephone, AC adapter, Fax, Small
size fluorescent light, VCR, TV as AC line common mode chokes.
RoHS Compliance.
Inductance measurement condition:1kHz, 1V
The above information are for reference only.
